H3C V7交换机WEB登录设备方法

进入系统视图

[016PV5-EI]display version
H3C Comware Software, Version 7.1.070, Release 6319P01
Copyright (c) 2004-2020 New H3C Technologies Co., Ltd. All rights reserved.
H3C S5016PV5-EI uptime is 0 weeks, 6 days, 1 hour, 4 minutes
Last reboot reason : Cold reboot

Boot image: flash:/s5000v5_ei-cmw710-boot-r6319p01.bin
Boot image version: 7.1.070, Release 6319P01
  Compiled Aug 14 2020 11:00:00
System image: flash:/s5000v5_ei-cmw710-system-r6319p01.bin
System image version: 7.1.070, Release 6319P01
  Compiled Aug 14 2020 11:00:00
<016PV5-EI>system-view
System View: return to User View with Ctrl+Z.
[016PV5-EI]

创建本地用户admin，并设置登录密码为admin，服务类型为http跟https，用户级别为network-admin管理员级别

[H3C] local-user admin   //创建本地用户admin

[H3C-luser-manage-admin] password simple admin   //设置登录密码为admin

[H3C-luser-manage-admin] service-type http https   //服务类型为http跟https

[H3C-luser-manage-admin] authorization-attribute user-role network-admin   //用户级别为network-admin管理员级别

[H3C-luser-manage-admin] quit   //退出当前视图

配置交换机的管理地址

[H3C] interface vlan-interface 1   //进入vlan1虚接口

[H3C-VLAN-interface1] ip address 192.168.1.58 255.255.255.0   //配置IP地址为192.168.1.50，掩码为24位

[H3C-VLAN-interface1] quit   //退出当前视图

#开启http跟https服务

[H3C]ip http enable   //开启http服务

[H3C]ip https enable   //开启https服务

#保存配置

[H3C]save force   //保存配置

此时打开浏览器，地址栏输入交换机的管理地址即可登录WEB界面。也可以使用https://192.168.22.199访问， 这样的https的方式登录WEB进行管理,在“WEB用户登录”对话框中输入用户名、密码及验证码，点击<登录>按钮后即可登录，显示WEB初始页面。成功登录后，用户可以在配置区对设备进行相关配置
